model： zdd 3-phase/1-phase online ups (6k~20k)
brand： gooden
specification：
zdd series ups is adopting the technology , which combined with the world's most advanced dsp digital control technology currently, and igbt high frequency pulse width modulation technique (pwm). double- conversion online topology design makes the output frequency of ups, which used for tracking, phase-locking, voltage regulator and filter out noise, interference from the power grid fluctuations in pure sine wave power supply, and make the ups more comprehensive and perfectly protection for the
product introduction
zdd series ups is adopting the technology , which combined with the world's most advanced dsp digital control technology currently, and igbt high frequency pulse width modulation technique (pwm). double- conversion online topology design makes the output frequency of ups, which used for tracking, phase-locking, voltage regulator and filter out noise, interference from the power grid fluctuations in pure sine wave power supply, and make the ups more comprehensive and perfectly protection for the users. after gooden r&d center elaborative designed for more than 10 years for the modular structure, whose overall operation is 5 times more reliable and stable performance than regular ups, mtbf is over 300,000 hours.
zdd series ups equipped with standard built-output isolation transformers, static bypass switch and manual maintain switch , making this series ups has a very high capacity to engage in short-circuit.lt could be used for the worst environment . also it has perfect protect function.moreover, it has the ac input, over-voltage, under- voltage, output over-voltage, short circuit protection, inverter, rectifier over-temperature protection, voltage under-voltage warning, battery over charging protection and other protections in one, to ensure system operation stably and reliably.
zdd series ups includes 3-phase ins and single-phase outs from 6k-20k, which can be in parallel with 8 units ups directly, conveniently and fast .flexible parallel technology could be applied to different loads and systems.according to the needs of customers' constitute, it could make n 1 or n x construction, but also according to the different needs of customers with different capacity, it could be in parallel with random 8 units ups, and all the load will be loaded by all 8 units ups averagely of the parallel redundant ups system. any ups of the parallel redundant system was failed, the others ups will share its load immediately, to ensure system running normally. during the process of the parallel ups , it does not set the host and the standby one , but was selected by customers flexibly. the first turned on ups is automatically set to the host, when the host system failed,the host identity immediately transferred to another ups, thereby ensuring the supply of electricity for clients during the using process, so it could become a true uninterruptible power supply.
technical specification
1. dsp digital control technology
core system uses the world's most advanced all- digital dsp control technology, which can effectively guarantee the ups' core system accurate, and fast running.
2. advanced igbt inverter technology
combined high-reliable and high-efficiency igbt inverter technology with high-frequency pulse width modulation technology (pwm).it could reduce noise and power loss, to ensure users can load in a variety of working situations and obtain high-quality voltage output and maximum cost-effectiveness, but also make input efficiency more than 95%.
3. pure-online double conversion technology
reliable and stable, after filtered and regulated, the output sine wave from pure-online double conversion technology, not only has the atmospheric disturbance suppression filter, but also with the standard output isolation transformers, static bypass, maintenance bypass, make this product with higher ability to engage in short circuit current. and it can be applied to the worst working environment.
4. perfect protection
perfectly system protection functions: it has ac over-voltage, under-voltage, output over-voltage, under-voltage, output overload, short circuit protection, inverter, rectifier over-temperature protection, voltage under-voltage warning, battery over charging protection and other protections in one to ensure the system to operate stably and reliably.
5. powerful communication system
the standard equipped with rs232 interface, do contact relays, emergency switching device epo input interface.
6. powerful redundant parallel connection function
durable and reliable design of industrial-type modular structure, combined with full digital dsp control technology core system, make this product not only can be used for n 1/n x redundancy and the ability of enlarge the capacity, but also permit different power and different times of the ups could be in parallel. it greatly reduced the user's pre-and post-purchasing costs, and increased capacity costs, but also expanded upper spaces of increasing capacity.
7. low-power dissipation but high-efficiency
to achieve more than 98% of ultra-high efficiency under eco economic model, which can effectively bring down the amount of electricity, and effective in accordance with the requirements of energy- saving target of the country.
8. prediction warning system
lcd panel automatic detection function and timely warning in advance, with the boot self-diagnosis function. it could avoid the hidden danger in time due to ups' failure, which caused risks. also it could automatically alarm by setting the battery discharge to standby time is less than a set value.
9. humanized panel display
humanized panel settings, the users can set system parameters, date, output voltage, battery capacity, alarm function, light-load shutdown, system boot time, modem settings, such as orders, also it can be up to 120 abnormal failure information for users to query.
10. super-strong environment adaptability
this product has superior environmental adaptability, wide ac input range, greatly reduces the frequency of battery using, and effectively extends the battery life.
11. powerful overload ability
300min/10min/1min
60min/10min/1min
using the pure-online double conversion technology, with the output isolation transformers, static bypass, and maintenance bypass. inverter overload ability reached 110% / 125% / 150% overloading time can last for 300min/10min/1min.bypass overload ability reached 150% / 170% / 250% overloading time can last for 60min/10min/1min.
12. advanced communication features
1) operating parameters display
voltage, current, frequency, battery temperature, load percentage, the current load back-up battery time remaining.
2) alarm information
up to more than 120 common used information and internal fault alarm in actual-time records. when the machine fails, ups system will automatically record fault code and the time, and the code content can be referenced for the user's manual.
3) command
battery test, system shutdown, parameter settings, and also can shut down the ups emergently on the lcd or on remote control panel.
4) operation parameter setting
to set the current date, output voltage, battery capacity, alarm function, light-load shutdown, the system timer switch machine, modem settings and so on.
5) battery manmgement function
display input / output bypass voltage, frequency, load percentage, battery backup time and so on. to start battery test, we can obtain the battery voltage, current, discharge time and other data. to set forecast alarm function, also it could automatically alarm by setting the battery discharge to standby time is less than a set value.
6) supported software interface
windows9x、2000、nt、me、xp、linux、novell、macosx、nt4.0
windows9x, 2000, nt, me, xp, linux, novell, macosx, nt4.0, etc.
range of applications
industrial automatic control
medical/hospital equipment
office automation
production equipment
electronic & telecom
aeronautics & astronautics
army technology
securities system
municipal project
industrial production line
glass making factory
ceramic making factory
renewable energy
sluge treatment plant
smt/ smd
pick and place smt machine
reflow oven
cnc processing machine
technical specification
